Product
Turbidity meter
Model
ADU3100
Display
128 * 64 dot matrix LCD with LED backlight,
which can be operated under the direct sunlight
Power supply
AC:85~500V, 50Hz/60Hz; DC: 9~36VDC
Output
Three-way analog output 4-20mA,
Note: the maximum load is 500 ohms
Relay
Three-way relay can be set up
Digital communication
MODBUS RS485 communication function,
which can transmit real-time measurements
Warranty period
1 year
Material of outside shell
Lower casing: Aluminum with powder covering
cover: PA66+GF25+FR
Storage temperature
-20~70℃
Operation temperature
-15~60℃
Ingress protection
IP65/NEMA4X
Size
145*125*162mm L*W*H
Weight
1.35KG
