WSR700 Radar level meter

General Information

Radar level transmitter can perform non-contact continuous measurement of the height of liquids in closed or open containers in industrial production processes.
The radar level transmitter has a long detection distance and low beam energy, and can be installed in various metal and non-metal containers or pipelines. It is suitable for occasions where dust, water mist, inert gas and steam exist. The radar level transmitter has no harm to the human body and the environment, and has the advantages of not being affected by the specific gravity of the medium, not being affected by the change of the dielectric constant, and not requiring on-site calibration.

SPECIFICATION

Product
Radar level meter
Model
WSR150
Measure range
8m / 15m
Modulation waveform
FMCW
Transmission frequency
79GHz~81GHz
Blind zone
≤0.15m
Antenna Angle
±3°
Accuracy
±5mm
Repeatability
±2mm
Refresh rate
≥500ms
Ingress protection
IP67
Transmission output
(4~20) mA
Communication output
RS485
Power supply
(9~36) VDC
Working current
≤80mA, 24VDC
Power consumption
≤1.9W
Dielectric constant
≥3
Process pressure
(-0.1~0.3) MPa
Process temperature
(-40~85)℃
