SUP-P300 Pressure transmitter with compact size for universal use

General Information

Combining a general-purpose detector with an amplifier, the ModMAG® M2000 Electromagnetic flow meter features an advanced, user-friendly design that is built for field verification testing with the use of a simple, handheld device.
REQUEST A QUOTE
CONTACT US

SPECIFICATION

Product
Pressure transmitter
Model
SUP-P300
Measure range
-0.1MPa…0~10kPa…60Mpa
Pressure type
Gauge pressure, Adiabatic pressure, Sealing pressure
Accuracy
0.5% F.S; 0.2%F.S,0.25%F.S, optional
Output signal
4~20mA; 1~5V; 0~10V; 0~5V; RS485
Temperature compensation
-10~70 ℃
Working temperature
-20~85 ℃
Medium temperature
-20~85 ℃
Storage temperature
-40~85 ℃
Overload pressure
0.035~10MPa（150%FS）, 10~60MPa（125%FS）
Long-term stability
± 0.2%FS/year
Power supply
10~32V (4~20mA); 12~32V (0~10V); 8~32V (RS485, 0~5V, 1~5V)
Ingress protection
IP65
