SUP-R6000F Paperless recorder

General Information

Combining a general-purpose detector with an amplifier, the ModMAG® M2000 Electromagnetic flow meter features an advanced, user-friendly design that is built for field verification testing with the use of a simple, handheld device.
REQUEST A QUOTE
CONTACT US

SPECIFICATION

Product
Paperless recorder
Model
SUP-R6000F
Display
7 inch TFT display screen
Input
Up to 36 channels of universal input
Relay output
2A/250VAC, Max 8 channels
Installation panel thickness
1.5mm~16.0mm
Weight
1.06kg
Internal memory
128 Mbytes Flash
Power supply
(176~264) VAC, 47~63Hz
Power consumption
30 VA,15W
Dimensions
193*162*144mm
DIN panel cutout
138.5*138.5mm
Relative humidity
(10~85)%RH
Operation temperature
(0~50)℃
Relative humidity
(10~85)%RH
Storage condition
temperature(-20~60)℃ relative humidity(5~95)%RH
